Description

Features
  • 300% Power Pre-Stretch, 1 Meter Film Pre-Stretched Will Be Stretched To 4 Meters
  • Turntable Home Position
  • Soft Start and Stop
  • Choices of Automatic or Manual Modes
  • Adjustable Top and Bottom Wrap Counts
  • Adjustable Wrapping Tension, Turntable Speed and Carriage Speed
  • 180° Rotating Control Box
  • Trouble Shooting Shown On Screen
  • Manual Reinforcing Wrapping
  • Safety Switch to Prevent From Foot Pitch
  • Height Detection By Photo Sensor
  • Advanced Soft Wrapping
  • Automatic Film Pin Puncture
  • One Way Idle Roller
  • Desinged To Allow Film Tail To Stay Outside Of Carriage When Break
Specifications
  • Max. Wrapping Height 2 M
  • Max. Turntable Speed 12 rpm
  • Max. Loading Weight 1650 kg
  • Turntable Diameter 1500mm
  • Power Supply 100V/110V/220V/230V/240V. 50/60HZ. 1-Phase.
  • Power Consumption 1.2 kw
  • Turntable Motor 220V. AC. 3-Phase
  • Carriage Motor 220V. AC. 3-Phase
  • Power Pre-Stretch Motor 220V. AC. 3-Phase
Options
  • Turntable Diameter 1.65M (Max. Loading Weight: 1650kg) or 1.8M (Max. Loading Weight: 2000kg).
  • Wrapping Height: 2.5M, 3.0M.
  • Ramps for 1.5M, 1.65M, 1.8M
  • Turntable Type  Horse Shoe 1.65M (Max. Loading Weight 1200kg)
  • Weighing Scale 1.65M Max. Loading Weight 2000kg)
  • Top Pressure Plate
  • Photo Sensor for Black Film
