Description

Specifications
  • Seal Length: 500mm
  • Maximum Product Height: 175mm
  • Useful Chamber Size: Width 500mm X Depth 500mm X Height 175mm
  • Outside Dimension: Width 695mm X Depth 680mm X Height 1035mm
  • Standard Voltage: 400-3-50Hz
  • Power Consumption: 3.3kW
  • Weight: 150kg
Options
  • Digital Time Control: 1 or 10 programs
  • Sensor Control: sensor/ H2O
  • Seal: double/ trenn/ 1-2/ bi active
  • Seal Configuration: S&S
  • Gas Option
  • Pump Capacity: 40m3 or 63m3
  • Cycle Time: 25-35 seconds
Seal Configuration

tv-mobile-m70-v2-222
